Black finishes throughout the engine and exhaust system, more premium paint options, and a new vintage-inspired tank medallion.
Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered
Loading 360 images
DRAG BIKE FOR 360 VIEW
Revolution® Max 1250T
125 Nm
228 KG
2,270 mm
Strong and understated, the blacked-out Revolution Max 1250T powertrain features a mix of gloss and matte black finishes for depth and contrast.
Premium paint options now include Factory Custom color Mystic Shift, which changes from a dark gunmetal to purple to blue, and finally to an almost orange in full sunlight.
With a flat line running through the gas tank and tail section, a tubular frame, and the new "Checkered V" tank medallion, it nods to Sportster® heritage while delivering the performance that today’s riders expect.
Big, beefy, 432 mm front tire provides responsive handling and a strong, muscular look.
Type | Revolution® Max 1250T |
Bore | 105 mm |
Stroke | 72.3 mm |
Displacement | 1,252 cc |
Compression Ratio | 12.0:1 |
Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) |
Exhaust | 2-into-1-into-2; catalyst in muffler |
Length | 2,270 mm |
Seat Height, Unladen | 765 mm |
Ground Clearance | 90 mm |
Rake (Steering Head) (Deg) | 30 |
Trail | 148 mm |
Wheelbase | 1,520 mm |
Tires, Front Specification | 160/70TR17 73V |
Tires, Rear Specification | 180/70R16 77V |
Tyre, Type | Dunlop® Harley-Davidson Series, radial |
Fuel Capacity | 11.7 l |
Oil Capacity (W/Filter) | 4.5 l |
Weight, In Running Order | 228 kg |
Engine Torque Testing Method | EC 134/2014 |
Engine Torque | 125 Nm |
Engine Torque (RPM) | 6000 |
Horsepower | 121 HP / 90 kW @ 7500 rpm |
Lean Angle, Right (DEG.) | 35 |
Lean Angle, Left (DEG.) | 35 |
Fuel Economy Testing Method | EU 134/2014 |
Fuel Economy | 5.1 l/100 km |
Co2 Emissions Testing Method | EU 134/2014 |
Co2 Emissions | 125 g/km CO2 |
Primary Drive | Gear, 49/89 ratio |
Gear Ratios (Overall) 1st | 12.21 |
Gear Ratios (Overall) 2nd | 9.022 |
Gear Ratios (Overall) 3rd | 6.994 |
Gear Ratios (Overall) 4th | 5.641 |
Gear Ratios (Overall) 5th | 4.731 |
Gear Ratios (Overall) 6th | 4.131 |
Front Fork | 43 mm inverted fork with compression, rebound and spring preload adjustability. Aluminum fork triple clamps. |
Rear Shocks | Linkage-mounted, piggyback monoshock with compression, rebound and hydraulic spring preload adjustability |
Wheels, Front Type | Aluminum cast, satin black |
Wheels, Rear Type | Aluminum cast, satin black |
Brakes, Caliper Type | Front: radially mounted, monoblock, 4-piston caliper Rear: floating, single piston caliper |
Lights (As Per Country Regulation), Indicator Lamps 6 | Headlamp: All LED headlamp, low and high beam with signature position lighting; Tail/Stop: All LED rear lighting; Front Signal Lights:LED Bullet Turn Signals |
Gauges | 4 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigation (H-D App ONLY) |
Type | Color TFT |
Screen Size | 102 mm |
Headset Specifications (If Equipped) | Bluetooth |
Languages | Arabic Chinese (Simplified/Traditional) Czech Danish Dutch English (default) Finnish French (Canada/France) German Greek Hungarian Italian Japanese Korean Norwegian Polish Portuguese (Portugal/Brazil) Indonesian Russian Slovak Spanish (Mexico/Spain) Swedish Thai Turkish Vietnamese |
Hands-free Mobile Phone - Via Bluetooth | Standard |
Voice Recognition Languages: Phone Functions Only | Phone dependent |
Voice Recognition Languages: Tuner/Media/Navigation | Phone dependent |
Text-to-speech (TTS) Languages | Phone dependent |
Rider/Passenger Intercom | Headset function only |
Vehicle Information Screen (Air Temperature, Oil Pressure and EITMS) | TPMS, Engine temp, Battery Voltage, Ambient Air Temp |
USB | Charging and Instrument update, USB-C, 5V, 3A |
Bluetooth | Phone/Media Supported |
