The 2025 Fat Boy is more fun than ever before with a new, high-performance Milwaukee-Eight® 117 Custom engine, a high-flowing, two-into-two exhaust system, and improved suspension.
Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered
Loading 360 images
DRAG BIKE FOR 360 VIEW
Milwaukee-Eight® 117 Custom
168 Nm
315 kg
675 mm
The best factory paint in the world covers a classic rounded gas tank that is finished with a new, bold tank medallion.
457mm machined Lakester wheels with massive tires are covered by cutback fenders for powerful stance and commanding presence.
The iconic Fat Boy headlight nacelle shines in bright polished chrome, accentuating the large and muscular look of the front end.
Milwaukee-Eight® 117 Custom V-twin engine delivers sound, feel, and all the power you need for effortless long-mile highway cruising or exhilarating in-town performance.
Type | Milwaukee-Eight® 117 Custom |
Bore | 103.5 mm |
Stroke | 114.3 mm |
Displacement | 1,923 cc |
Compression Ratio | 10.3:1 |
Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) |
Exhaust | 2-into-2 staggered; catalyst in muffler |
Length | 2,365 mm |
Seat Height, Unladen | 675 mm |
Ground Clearance | 125 mm |
Rake (Steering Head) (Deg) | 30 |
Trail | 104 mm |
Wheelbase | 1,650 mm |
Tires, Front Specification | 160/60R18,70V,BW |
Tires, Rear Specification | 240/40R18,79V,BW |
Fuel Capacity | 18.9 l |
Oil Capacity (W/Filter) | 4.7 l |
Weight, In Running Order | 315 kg |
Engine Torque Testing Method | EC 134/2014 |
Engine Torque | 168 Nm |
Engine Torque (RPM) | 3,000 |
Horsepower | 103 HP / 77 kW @ 5020 rpm |
Lean Angle, Right (DEG.) | 25.6 |
Lean Angle, Left (DEG.) | 25.6 |
Fuel Economy Testing Method | EU 134/2014 |
Fuel Economy | 5.5 l/100 km |
Co2 Emissions Testing Method | EU 134/2014 |
Co2 Emissions | 128 g/km CO2 |
Primary Drive | Chain, 34/46 ratio |
Gear Ratios (Overall) 1st | 9.311 |
Gear Ratios (Overall) 2nd | 6.454 |
Gear Ratios (Overall) 3rd | 4.793 |
Gear Ratios (Overall) 4th | 3.882 |
Gear Ratios (Overall) 5th | 3.307 |
Gear Ratios (Overall) 6th | 2.79 |
Front Fork | Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers |
Rear Shocks | Hidden, free piston, coil-over monoshock; 43mm stroke; hydraulic preload adjustment |
Wheels, Front Type | Machined, Lakester cast aluminum |
Wheels, Rear Type | Machined, Lakester cast Aluminium |
Brakes, Caliper Type | 4-piston fixed front and 2-piston floating rear |
Lights (As Per Country Regulation), Indicator Lamps 6 | Headlamp: All LED headlamp, low and high beam with signature position lighting; Tail/Stop: Bullet-style, LED stop/tail/turn signals; Front Signal Lights: LED Bullet Turn Signals |
Gauges | 5-inch analog speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication |
